Flicker Free (<3%)
Selectable Lumen Output

Silver (SV12)
Class II
Beam 120

Photometric Diagram
Lux-cone Diagram
Photometric Diagram
Lux-cone Diagram
     Family Datasheet
     Product Datasheet
Model no.:


Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50
Input Current (mA) 60/40
Output Voltage (V) DC 135
Output Current (mA) 50/30
Power Factor (λ) >0.5
Total Harmonic Distortion 125% / 140%
Product Data
Product Wattage (W) 7.5/4.5
Light Source Integrated LED-3000 / Integrated LED-4000
Beam Angle (°) 120
Colour Render Index (Ra) Ra80
Colour Silver (SV12)
Protection Class CL II
Colour Consistency (SDCM) 6
Dimmable No
Operating Temperature -30°C to +40°C
Ambient Temperature Range (Ta) 40
Switching Cycles (times) 100,000
Mercury Content (mg) N/A
Weight (g) 160
Application Car parks, Corridors, Garden and balcony, Public area, Stairwells
Performance Data
Rated Life (hrs) 25,000
IP Rating IP54/IP54
Product Dimensions
Length (mm) 167
Width (mm) 115
Height (mm) 79
