Family Datasheet
Product Datasheet
FBH70000v0-ds/sc+LA11157
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50-60 |
| Power Factor (λ) | > 0.7 |
| Product Data | |
| Product Wattage (W) | 14 |
| Light Source | Integrated LED-3000/4000 |
| Colour Render Index (Ra) | ≥ Ra80 |
| Protection Class | CL II |
| Colour Consistency (SDCM) | ≤ 6 |
| Operating Temperature | 0°C to +40°C |
| Switching Cycles (times) | > 100000 |
| Weight (g) | 1015 |
| Performance Data | |
| Luminous Flux (lm) | 900 [3000K] / 1000 [4000K] |
| Luminous Efficacy (lm/W) | 64 [3000K] / 71 [4000K] |
| IP Rating | IP66/IP66 |
| Product Dimensions | |
| Diameter (mm) | 300 |
| Height (mm) | 85 |
