Family Datasheet
     Product Datasheet
Model no.:


Electrical Data
Voltage (V) 220-240V
Power Factor (λ) >0.9
Product Data
Product Wattage (W) 5
Light Source Integrated LED-4000
Colour Render Index (Ra) ≥ Ra80
Colour White (WH11)
Protection Class CL II
Colour Consistency (SDCM) ≤6
Operating Temperature -30°C to +40°C
Switching Cycles (times) 100000
Weight (g) 73
Application Display Shelves, Light Troughs, Offices, Shops and Boutiques, Wall Lighting
Performance Data
Luminous Efficacy (lm/W) 120
IP Rating IP20/IP20
Product Dimensions
Length (mm) 300
Width (mm) 24
Height (mm) 35
