Family Datasheet
     Product Datasheet
Model no.:

FDM71700v0

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60 Hz
Power Factor (λ) >0.5
Product Data
Product Wattage (W) 9
Light Source Integrated LED-6500
Colour Render Index (Ra) Ra80
Protection Class CL II
Colour Consistency (SDCM) SDCM ≤ 6
Operating Temperature -30°C to +40°C
Switching Cycles (times) 100000
Weight (g) 80
Application Retails, Hotels, Kitchens, Offices, Restaurants
Performance Data
Luminous Flux (lm) 720
Luminous Efficacy (lm/W) 80
IP Rating IP20/IP20
Product Dimensions
Diameter (mm) 125
Height (mm) 30
