Family Datasheet
     Product Datasheet
Model no.:

FDS73600v0-sc

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50
Power Factor (λ) >0.5
Product Data
Product Wattage (W) 2.2
Light Source Integrated LED-3000/4000
Colour Render Index (Ra) > Ra80
Colour White (WH12), Black (BK12), Brushed Nickel (NI52)
Protection Class CL II
Colour Consistency (SDCM) ≤6
Operating Temperature -30°C to +40°C
Switching Cycles (times) 100000
Weight (g) 48
Application Retails, Hotels, Kitchens, Offices, Restaurants, Under cabinet
Performance Data
Luminous Flux (lm) 160/170
Luminous Efficacy (lm/W) 69/75
IP Rating IP20/IP20
Product Dimensions
Diameter (mm) 64
Height (mm) 21
