DINO 2 Waterproof Batten (Integrated) - Opal Prismatic Diffuser Options - Permanent Live
![Silver (SV16) Silver (SV16)](/var/files/products/colour/colour_SV.png)
![IP66 IP66](/var/files/products/specifications/IP66.png)
![IK08 IK08](/var/files/products/specifications/IK08.png)
![Class II Class II](/var/files/products/specifications/class_II.png)
![Beam 120 Beam 120](/var/files/products/specifications/beam_120.png)
-
IES File
-
Control Gear (PDF)
-
Containing Product (PDF)
-
Light Source (PDF)
![](/var/files/products/line_drawing/megaman/luminaires/FOB61600v1-pl.png)
Integrated LED Luminaire
FOB61600v1-pl
![Photometric Diagram](/var/files/products/indoor_luminaires/DINO_2/photometric_diagrams/FOB61600v1-pl_CD.png)
![Lux-cone Diagram](/var/files/products/indoor_luminaires/DINO_2/photometric_diagrams/FOB61600v1-pl_cone.png)
![](/images/icon_share_printer.png)
![](/images/icon_share_printer.png)
FOB61600v1-pl
Electrical Data | |
Voltage (V) | 220-240V |
Frequency (Hz) | 50/60 |
Input Current (mA) | 256 |
Power Factor (λ) | >0.9 |
Product Data | |
Product Wattage (W) | 53 |
Light Source | Integrated LED-4000 |
Beam Angle (°) | 160 |
Colour Temperature (K) | Warmwhite (3000K), Coolwhite (4000K) |
Colour Render Index (Ra) | Ra80 |
Colour | Silver (SV16) |
Materials | Polycarbonate with opal prismatic diffuser |
Protection Class | CL II |
Colour Consistency (SDCM) | 6 |
Dimmable | no |
Operating Temperature | -30°C to +50°C |
Ambient Temperature Range (Ta) | 25 |
Switching Cycles (times) | 100000 |
Weight (g) | 1063 |
Application | Car parks, Underground Areas, Warehouses, Workshops |
Performance Data | |
Luminous Flux (lm) | 7460 |
Rated Useful Luminous Flux (lm) | 7460 |
Luminous Flux (lm) | 6300 [3000K], 6500 [4000K] |
Luminous Efficacy (lm/W) | 100 [3000K], 103 [4000K] |
Rated Life (hrs) | 50000 hrs at L80, B10 at Ta 25°C |
Rated Life (hrs) | 50,000hrs L80B10@Ta25°C |
IP Rating | IP66/IP66 |
Product Dimensions | |
Length (mm) | 1623 |
Width (mm) | 60 |
Height (mm) | 54 |
Remarks DC Input Voltage:200-250VDC,可匹配LA11156 |
