Family Datasheet
     Product Datasheet
Model no.:

FCL71800v0-ds+LA10175

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60 Hz
Power Factor (λ) >0.7
Product Data
Product Wattage (W) 23/16/11
Light Source Integrated LED-4000
Beam Angle (°) 120
Colour Render Index (Ra) > Ra80
Protection Class CL I
Colour Consistency (SDCM) <6
Operating Temperature -20°C to +40°C
Switching Cycles (times) 100000
Weight (g) 765
Application Bathrooms, Corridors, Foyers, Hotels, Living Rooms, Residential applications, Under Canopy
Performance Data
Luminous Efficacy (lm/W) 87/88/91
IP Rating IP44/IP44
Product Dimensions
Diameter (mm) 390
Height (mm) 115
