IES File
Family Datasheet
Product Datasheet
FCL73000v0-ds
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50 |
| Input Current (mA) | 145 |
| Power Factor (λ) | 0.5 |
| Product Data | |
| Product Wattage (W) | 14.5 |
| Light Source | Integrated LED-6500 |
| Beam Angle (°) | 120 |
| Colour Render Index (Ra) | Ra80 |
| Protection Class | CL II |
| Colour Consistency (SDCM) | 6 |
| Dimmable | no |
| Operating Temperature | -20°C to +40°C |
| Ambient Temperature Range (Ta) | 25 |
| Switching Cycles (times) | 25000 |
| Weight (g) | 570 |
| Application | Corridors, Hotels, Kitchens, Living Rooms, Residential applications |
| Performance Data | |
| Luminous Flux (lm) | 1700 |
| Rated Useful Luminous Flux (lm) | 1700 |
| Rated Life (hrs) | 25,000hrs L70B50@Ta25°C |
| IP Rating | IP20/IP20 |
| Product Dimensions | |
| Diameter (mm) | 294 |
| Height (mm) | 23 |
