54W/7W GX53 700lm 6500K Ra80 Non-Dim

GX53

Spectral Power Distribution

Family Datasheet

Product Datasheet

Product Code:

Electrical Data
Voltage (V)	220-240V
Frequency (Hz)	50/60 Hz
Current (mA)	40
Power Factor (λ)	≥ 0.70
Starting Time (sec)	< 0.5 s
Warm-up Time Up to 60% of the Full Light Output (sec)	Instant
Product Data
Lamp Base	GX53
Product Wattage (W)	7
Equivalent Wattage (W)	54
Colour Temperature (K)	6500
Colour Render Index (Ra)	Ra80
Colour Consistency (SDCM)	6
Dimmable	No
Operating Temperature	-30°C to +40°C
Switching Cycles (times)	> 100000
Weight (g)	32
Application	Corridors, Display Cabinets, Hospitality Installations, Residential lighting, Retail shops
Performance Data
Luminous Efficacy (lm/W)	100
Rated Life (hrs)	15000
Product Dimensions
Diameter (mm)	75
Width (mm)	75
Height (mm)	24

Indoor
