GX53

F





Spectral Power Distribution
Spectral Power Distribution
     Family Datasheet
     Product Datasheet
Product Code:

LR209049-OPv00-ND+GX53+827+V0240

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60 Hz
Current (mA) 40
Power Factor (λ) ≥ 0.50
Starting Time (sec) < 0.5 s
Warm-up Time Up to 60% of the Full Light Output (sec) Instant
Product Data
Lamp Base GX53
Product Wattage (W) 4.9
Equivalent Wattage (W) 43
Colour Temperature (K) 2700
Colour Render Index (Ra) Ra80
Colour Consistency (SDCM) 6
Dimmable No
Operating Temperature -30°C to +40°C
Switching Cycles (times) > 100000
Weight (g) 32
Application Corridors, Display Cabinets, Hospitality Installations, Residential lighting, Retail shops
Performance Data
Luminous Efficacy (lm/W) 106
Rated Life (hrs) 15000
Product Dimensions
Diameter (mm) 75
Width (mm) 75
Height (mm) 24
