100W/8.5W E27 667lm 2700K Ra80 Non-Dim

R50, R63, R80

F





Photometric Diagram
Lux-cone Diagram
Spectral Power Distribution
Spectral Power Distribution
     Family Datasheet
     Product Datasheet
Product Code:

LR221085-OPv00-WF+E27+827+V0240

Electrical Data
Voltage (V) 220-240V
Frequency (Hz) 50/60 Hz
Current (mA) 58
Power Factor (λ) ≥ 0.50
Starting Time (sec) < 0.5 s
Warm-up Time Up to 60% of the Full Light Output (sec) Instant
Product Data
Lamp Base E27
Product Wattage (W) 8.5
Equivalent Wattage (W) 100
Colour Temperature (K) 2700
Colour Render Index (Ra) Ra80
Colour Consistency (SDCM) 6
Dimmable No
Operating Temperature -30°C to +45°C
Switching Cycles (times) > 100000
Weight (g) 133
Application Exhibition Halls, Reception Areas, Restaurants and Lounges, Shops and Boutiques, Showrooms
Performance Data
Max. Luminous Intensity (cd) 1150
Luminous Flux in 90° cone (lm) 667
Luminous Efficacy (lm/W) 95
Rated Life (hrs) 15000
Product Dimensions
Diameter (mm) 80
Width (mm) 80
Height (mm) 110
