A60

     Family Datasheet
     Product Datasheet
Product Code:

LG7206w-B22-2700K-230V

Electrical Data
Voltage (V) 220-240V
Power Factor (λ) > 0.85
Starting Time (sec) < 0.5 s
Warm-up Time Up to 100% of the Full Light Output (sec) Instant full light
Product Data
Lamp Base B22
Product Wattage (W) 6
Equivalent Wattage (W) 40
Colour Temperature (K) Dim to Warm (2700-1800)
Colour Render Index (Ra) Ra80
Colour Consistency (SDCM) SDCM ≤6
Dimmable 100-5%
Operating Temperature -30°C to +40°C
Switching Cycles (times) >1000000
Weight (g) 110
Application Hospitality, Residential
Performance Data
Total Luminous Flux (lm) 470
Rated Life (hrs) 25000
Lumen Maintenance at the End of Lamp Life (%) ≥90
Product Dimensions
Diameter (mm) 60
Length (mm) 110
Remarks
The rated wattage, rated lamp life and rated luminous flux are equivalent to their nominal values, which show on the product packaging.

Technologies

  • U-DIM
    Compatible with the widest range of existing dimmers, whether they are leading-edge or trailing edge dimmers, with enhanced dimming range of 100% down to 5%.
  • Dim-to-Warm
    Following exactly the dimming curve of familiar incandescent and halogen lamps, the LED lamps could simultaneously emit a warmer light when they are dimmed from 100% to 5%.
