FBH70000v0-ds/sc
Family Datasheet
Product Datasheet
FBH70000v0-ds/sc
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50-60 |
| Power Factor (λ) | > 0.9 |
| Product Data | |
| Product Wattage (W) | 22/15/10 |
| Light Source | Integrated LED-3000/4000 |
| Beam Angle (°) | 110 |
| Colour Render Index (Ra) | ≥ Ra80 |
| Protection Class | CL II |
| Colour Consistency (SDCM) | ≤ 6 |
| Operating Temperature | -30°C to +50°C |
| Switching Cycles (times) | > 100000 |
| Weight (g) | 825 |
| Application | Car parks, Corridors, Patios, Stairwells, Warehouses |
| Performance Data | |
| Luminous Flux (lm) | 2000 / 1500 / 1000 [4000K], 1850 / 1400 / 900 [3000K] |
| Luminous Efficacy (lm/W) | 91/100/100 [4000K], 84/93/90 [3000K] |
| IP Rating | IP66/IP66 |
| Product Dimensions | |
| Diameter (mm) | 300 |
| Height (mm) | 85 |
